University of Alabama Bryant Denny Stadium

PROJECT DESCRIPTION

UA Bryant Denny Stadium Renovations & Additions selective demolition and expansion of the existing Bryant Denny Stadium including upgrades to existing multi-floor box seating and new multi-floor box seating.

PROJECT AT A GLANCE

Location: Tuscaloosa, Alabama
General Contractor: Caddell Construction Company, LLC
Completion Date: August 2020
Project Budget: $17.45 Million

SPECIFICATIONS:

• Selective demolition and expansion of Bryant Denny Stadium
• Upgrades to existing multi-floor box seating
• New multi-floor box seating
• HVAC work included tie into existing campus chilled water system and new heating water system routed throughout area including new equipment
• Four new 2,000 MBH gas fired boilers
• Four HHW pumps
• Two CHW pumps
• One RTU
• 19 four-pipe AHUs
• 66 four-pipe FCUs
• Three refrigerant ductless split system units
• 55 HW air terminal units
• 39 exhaust fans
• Piping, ductwork, insulation, controls, test & balance, and commissioning
• BIM drawings
• Plumbing work included tie into existing sanitary, storm, and water system with new equipment
• 485 fixtures
• 126 kitchen connections
• Two 2000 MBH gas fire water heaters
• One 1,500 gallon HW storage tank
• New storm, sanitary, domestic water piping, and insulation
